PRODUCT SPECIFICATIONS

-For Use With – FX1N Series
-Number of I/O – 60
-Manufacturer Series – FX1N
-Number of Inputs – 36 (Digital)
-Voltage Category – 12 → 24 V dc
-Number of Outputs – 24 (Transistor)
-Program Capacity – 8000 Steps
-Programming Interface – Computer
-Programming Language Used – Ladder Logic
-Mounting Type – DIN Rail
-Minimum Operating Temperature – 0°C
-Depth – 75mm
-Dimensions – 90 x 175 x 75 mm
-Maximum Operating Temperature – +55°C
-Length – 90mm
-Output Current – 500 mA
-Width – 175mm
-Scan Time – 0.55 → 0.7 μs
