PRODUCT SPECIFICATIONS

-MPU points: 14 (8DI + 6DO)
-Max. I/O points: 494 (14 + 480)
-Program capacity: 8k steps
-COM port: Built-in RS-232 & RS-485 ports, compatible with
Modbus ASCII/RTU protocol. Can be master or slave.
-High-Speed Pulse Output：Supports 4 points (Y0 ~ Y3) of
independent high-speed (max. 10kHz) pulse output
-Supports PID Auto-tuning：DVP-SS2 saves parameters automatically
after the PID auto temperature tuning is completed.
-Built-in High-Speed Counters
