PRODUCT SPECIFICATIONS

– Digital Input: 24 (24V npn)
– Digital Output (peak current): 24
(12x 8A NPN, 12x 1A NPN)
– Digital I/O Expansion: Up to
128 DI, 128 DO
– Analog I/O: 12
– A.I. Interface 8 (0 to 5V, 12-bit)
– A.O. Interface 4 (0 to 5V, 12-bit)
– PWM (current): 4 (4A)
– Stepper Motor Controller: 3 (10,000 pps)
– Stepper Motor Drivers: 3 (unipolar)
– High Speed Counter: 3 (10 KHz)
– RS232 ports: 1
– RS485 port (2-wire): 2
– 14-pin LCD port: 1
– Ethernet Port: 1
– IR Remote Control: 1
– Light Dimmer control: 12
– Program Flash Memory: 23.5K words
– Non-volatie FRAM: 6K words built-in
– Dimension (L x W x H): 7.05” x 4.45” x 1.0”
– Weight 0.56 lbs / 257g
– Operating Temperature: 0-70 ℃
