Product characteristics

Output signal: switching signal; IO-Link; (configurable)

Measuring range: -1…10 bar

Process connection: threaded connection 1/4″ NPT internal thread

Application

Special feature: Gold-plated contacts

Measuring element: ceramic-capacitive pressure measuring cell

Application: for industrial applications

Media: liquids and gases

Medium temperature [°C]: -25…80

Min. bursting pressure: 150 bar

Pressure rating: 75 bar

Type of pressure: relative pressure; vacuum

MAWP (for applications according to CRN) [bar]: 50

Electrical data

Operating voltage [V]: 18…30 DC; (according to EN 50178 SELV/PELV)

Current consumption [mA]: < 35

Min. insulation resistance [MΩ]: 100; (500 V DC)

Protection class: III

Power-on delay time [s]: < 0.3

Integrated watchdog: yes
