Product characteristics

Output signal: switching signal; IO-Link; (configurable)

Measuring range: -1…10 bar

Process connection: threaded connection G 1/4 external thread internal thread:M5

Application

Application: for industrial applications

Media: liquids and gases

Medium temperature [°C]: -25…90

Min. bursting pressure: 150 bar

Pressure rating: 75 bar

Type of pressure: relative pressure; vacuum

Electrical data

Operating voltage [V]: 9.6…36 DC; (communication mode: 18…32)

Current consumption [mA]: < 45

Min. insulation resistance [MΩ]: 100; (500 V DC)

Protection class: III

Power-on delay time [s]: 0.3

Inputs / outputs

Number of inputs and outputs: Number of digital outputs: 2

Output signal: switching signal; IO-Link; (configurable)

Electrical design: PNP

Output function: normally open / normally closed; (parameterisable)

Overload protection: yes

Technical detail
